E58D feature an electronically controlled engine combined with an efficient load-sensing hydraulic system. The array of performance and comfort features available is comprehensive, and includes automatic air conditioning, front and rear LED lights, pneumatic suspension seats, integrated rearview camera, electric fuel refill pump, dozer float function, 6×1 dozer blade and many more.

​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​VERSATILE AND EXCEPTIONALLY PRODUCTIVE
Suiting applications from track, irrigation and drainage scheme construction ​and maintenance through to fencing, temporary building creation and crop support erection, New Holland mini crawler excavators have a operating weight range from 1.7 to 5.4 tonnes. By offering a line which covers the whole mini excavator category, the new D-series answers all your needs. With a choice of 6 models, there is one for every application across landscaping, amenity work, agriculture, horticulture, nurseries, vineyards, estate management and general contracting. The new D-series mini excavators are designed to work efficiently in every condition, outperforming the competition in terms of dump clearance and maximum reach. All models feature a compact tail design allowing work in the tightest spaces.

360° VISIBILITY
​​D-series mini excavators have been designed to offer a high level of comfort. All-round visibility is afforded by a large glazed area, a panoramic sky window and a powerful LED lights package.​​​​​

EMBEDED INNOVATION
​​​The 7” multicolour display allows customisation of several parameters, including flow rate settings for the auxiliary circuits, the fan drive automatic reversal interval, the auto-idle, sensitivity of the controls, the cab ventilation and many others. The display also acts as a self-diagnostic tool, reminding the operator when maintenance is due and keeping machine health parameters under control at all times.​​

EXTREMELY SILENT
​Extremely silent and powerful Stage V engines allow for work in the most challenging conditions. Not only do these models excel in terms of engine power and torque, but they are also extremely silent thanks to the hydraulic fan-drive cooling system. The fan speed is electronically controlled, so that heat exchange is optimised​ while noise level is kept to a minimum, since fan rotation speed is adjusted depending on the real time cooling needs. The fan can even rotate in inverted direction, enabling to keep radiators clean at all times. An efficient cooling system contributes to keeping fluid properties within parameters, maximising machine component life.​​​

MAINTENANCE MADE EASY
All models of the D-series have been designed to allow quick maintenance tasks: the engine hood, the radiator cover, the rear cover, the distributor guard and the fuse compartment guard can all easily be removed or opened, granting perfect accessibility to all service components. What’s more, the cab can easily be tilted forward, providing maximum accessibility to all machine components.​​

Specifications

ENGINE
Type Kubota – V2607-CR-T – Stage V
Max. Power 59.4hp
Number of cylinders 4
Consumption l/h 7.6l/h

HYDRAULIC SYSTEM
Max. circuit calibration pressure 280bar
Auxiliary system (max pressure): AUX 1 – single or double effect –
Auxiliary system (max pressure): AUX 1 – single or double effect 80l/min – 200bar
Auxiliary system (max pressure): AUX 2 – optional –
Auxiliary system (max pressure): AUX 2 – double effect – optional 60/40l/min – 280bar
Auxiliary system (max pressure): AUX 2 – double effect – optional –
Auxiliary system (max pressure): AUX 3 – optional 37l/min – 280bar
Auxiliary system (max pressure): AUX 3 – double effect – optional –

CONTROLS & DIGGING
Max Digging Depth 3570mm
Boom, dipper stick, bucket and turret swing 2 pilot joysticks
Track movements (included counter rotation) 2 pilot levers
Dozer blade pilot lever
Auxiliary system with latch AUX 1 (single or double effect) –
Priority auxiliary system with holding function AUX 1 (single or double effect) electroproportional switch on right joystick
Auxiliary system AUX 2 (double effect) –
Auxiliary system AUX 3 (double effect) –
Boom swing electroproportional switch on left joystick

WEIGHTS
Operating weight with canopy –
Operating weight with cab 4950kg

CIRCUIT AND COMPONENT CAPACITIES
Fuel tank 85l
Hydraulic oil tank 60l
